Foam Products

GREENGUARD Gold Certified.
GREENGUARD Gold Certification offers stricter certification criteria, considers safety factors to account for sensitive individuals (such as children and the elderly), and ensures that a product is acceptable for use in environments such as schools and healthcare facilities. It is referenced by both The Collaborative for High Performance Schools (CHPS) and the Leadership in Energy and Environmental Design (LEED) Building Rating System.

ADVANTAGES

Reduces floor noise by providing excellent sound absorption
Provides cushioned comfort under laminate and floating wood floors
The Eclipse II has high density and compression resistance properties that enable your floor to perform to its fullest potential and last a lifetime
The moisture barrier film and tape strip combine to lock out moisture and allow for quick and easy installation
Eliminates minor subfloor imperfections
The Eclipse II adds insulation value with an R-value of .29
Suitable for use with radiant heat flooring systems
100% recyclable, environmentally friendly, non allergenic and odorless

APPROVED SUBSTRATES

Dry, completely cured concrete (at least 14 days old with HVAC operating)

3/4" interior plywood or OSB flooring

Waterproofing and crack-isolation membranes

Cement backer units

QUICK AND EASY INSTALLATION

Subfloor surface must be clean and dry before installation.

Start on a corner of room wall. Unroll Eclipse II underlayment (film side down) over the subfloor.
Be sure tape strip side is next to the wall and overlapping film lip is toward the open room.

Roll out next row in the same manner butting foam close to first row and covering overlapping plastic film lip.
Do not overlap foam pad just the overlapping plastic film lip.

Remove tape liner and secure the overlapping plastic film lip to it. Continue with installation.
Seal all open seams with aggressive adhesive plastic tape.

Install flooring per manufacturer's instructions.

INSTALLATION GUIDE NOTE

In geographic regions where concrete slabs may be subject to higher moisture levels, a calcium chloride test is required. Vapor emission readings in excess of 3 lbs/1000sf in less than 24 hours will require additional protection such as a concrete sealant, moisture abatement, or 6 mil poly-ethylene sheeting. (please follow flooring OEM's instructions verbatim with regards to subfloor prep). It is mandatory to properly prep the subfloor to meet/exceed OEM installation instructions since the maximum value of most OEMs is 3 lbs MVTR with regards to adding an extra moisture abatement before putting down the underlayment (if on grade or below grade) and then the flooring product. Since we offer the industry's best warranty and track record and are willing to replace another company's floor parts and labor should our product fail, a properly prepared subfloor that meets/ exceeds every major OEMs subfloor prep protocol is mandatory. New construction installations should be performed only after the building is completely enclosed and the climate control system is in operation for a minimum of two weeks.

PACKAGING

Available in 43" x 27.9' (100 sq. ft.) rolls and 43" x 279' (1000 sq. ft.) contractor size rolls

TECHNICAL DATA

100% closed cell moisture resistant EVA foam rubber
Thickness — .070”
Weight — 5.5 lbs per roll
Moisture Protection — closed cell foam
Thermal Resistance — R-Value .29
Compression Resistance ASTM D3575 — 21.1 psi
Compression Set ASTM D3574 — 16.3%

SOUND ABSORPTION PROPERTIES

Impact Insulation Class (IIC) This method is to measure the impact sound transmission performance of a floor-ceiling assembly (sound transmission through the floor)

IIC	Flooring	Sub-Floor
72	Laminate	6" concrete with ceiling assembly
72	Engineered Wood	6” concrete with ceiling assembly
66	WPC	6” concrete with ceiling assembly
53	WPC	6” concrete NO ceiling assembly

Sound Transmission Class (STC) This method is to measure the air-borne sound insolating property of a partition element for effectiveness in blocking sound

STC	Flooring	Sub-Floor
66	Laminate	6” concrete with ceiling assembly
66	Engineered Wood	6” concrete with ceiling assembly
60	WPC	6” concrete with ceiling assembly
50	WPC	6” concrete NO ceiling assembly
