Foam Products Line Of Underlayments:

BEST
Silencer LVT

Eco Ultimate Silencer

Eco Silencer HD FOF

BETTER
Eco Silencer +

Silencer SR Blue

Silencer SR Pink

GOOD:
Eclipse II

BASE:
Premium PE Foam

Eco-Silencer+™
Acoustical Underlayment with Moisture Barrier
Eco-Silencer +
  • Suitable for floating laminate, engineered and hardwood flooring
  • Contains ultra•fresh, an antimicrobial protection that resists mold and mildew
  • Crushpruf™ technology resists indentation and extends the life of the floor
  • Provides cushioned comfort under hard laminate flooring
  • Eliminates minor subfloor imperfections
  • Offers the industry's best limited lifetime warranty
  • Suitable for radiant heat flooring systems
  • Install Eco-Silencer+ with film down against concrete/subfloor
  • GREENGUARD Gold Certified.
    GREENGUARD Gold Certification offers stricter certification criteria, considers safety factors to account for sensitive individuals (such as children and the elderly), and ensures that a product is acceptable for use in environments such as schools and healthcare facilities. It is referenced by both The Collaborative for High Performance Schools (CHPS) and the Leadership in Energy and Environmental Design (LEED) Building Rating System.
The Eco-Silencer+™ maintains the beauty of your floor like nothing else.
The Eco-Silencer+™ underlayment can stand up to the pressure.


ADVANTAGES
  • Eco-Silencer+™ is made with 100% post consumer recycled granulated rubber tires.
  • The moisture barrier film and tape strip combine to lock out moisture and allow for quick and easy installation.
  • Suitable for floating laminate, engineered and hardwood flooring
  • Contains ultra•fresh, an antimicrobial protection that resists mold and mildew
  • Crushpruf™ technology resists indentation that enables your floors to perform to its fullest potential and last a lifetime
  • Provides cushioned comfort under hard laminate flooring
  • Eliminates minor subfloor imperfections
  • Offers the industry's best limited lifetime warranty
  • Suitable for radiant heat flooring systems
  • Install Eco-Silencer+™ with film down against concrete/subfloor
APPROVED SUBSTRATES
  • Dry, completely cured concrete (at least 14 days old with HVAC operating)
  • 3/4" interior plywood or OSB flooring
  • Waterproofing and crack-isolation membranes
  • Cement backer units
FLOOR PREPARATION
  • Subfloor should be clean and dry
  • In geographic areas where concrete subfloors are subject to excessive moisture, a calcium chloride moisture test is required. Vapor emission readings in excess of 4 lbs. per 1,000 square feet in 24 hrs will require additional protection such as concrete sealant or polyethylene sheeting.
INSTALLATION
Quick and easy installation* – requires no additional seaming tape, cuts with a knife
  1. Install Eco-Silencer+™ with film DOWN on subfloor
  2. Roll out underlayment with tape strip next to wall. Roll out next row in same manner butting underlayment close to first row ( do not overlap ) and covering the moisture barrier film. Remove the tape strip and secure the overlapping moisture barrier film.
  3. Install flooring according to the manufacturer's installation instructions
    *NOT for glue down installations
PACKAGING
  • Available in 3' x 33.34' (100 sq. ft.) rolls and 6' x 75' (450 sq. ft.) contractor size rolls
TECHNICAL DATA
100% Synthetic SBR Rubber foam underlayment blended with post consumer recycled granulated rubber tires, includes attached moisture film
Thickness — .085"
Density — 16 LBS
Weight — 2.24 oz/sq.ft.
Moisture Barrier — with lip and tape sealing system
Antimicrobial Treatment — ultra•fresh
Thermal Resistance — R-Value .20
Compression Resistance @ 25% — 8.6 psi
Compression Set @ 25% — 10.3%
Flammability Rating — Passes Federal Flammability Standards DOC-FF-1-70
Smoke Density — Passes, 85 max
Product Emissions — Exceeds VOC emissions requirements, environmentally friendly
SOUND ABSORPTION PROPERTIES
Impact Insulation Class (IIC) This method is to measure the impact sound transmission performance of a floor-ceiling assembly (sound transmission through the floor)
IIC – Flooring – Sub-Floor
70 – Laminate/Engineered – 6" concrete with ceiling assembly
59 – Hardwood – 6" concrete with ceiling assembly
Sound Transmission Class (STC) This method is to measure the air-borne sound insolating property of a partition element for effectiveness in blocking sound
STC – Flooring – Sub-Floor
71 – Laminate/Engineered – 6" concrete with ceiling assembly
53 – Hardwood – 6" concrete with ceiling assembly
LEED Credits
MR 4.1 – 10% recycled content
MR 4.2 – 20% recycled content
MR 5.1 – 10% content manufactured within 500 miles of project
MR 5.2 – 20% content manufactured within 500 miles of project
EQ 4.3 – low emitting VOC's

ultra•fresh is a registered trademark of Thomson Research Associates Inc.
