Silencer SR acoustical underlayment is suitable for floating Laminate, Engineered and Hardwood plank flooring installations.Offers the best support, moisture protection and sound absorption for your floors.
- Reduces floor noise by providing excellent sound absorption
- Exceeds Air Quality and Flammability standards
- 100% recyclable and environmentally friendly
- Quick and easy installation (no additional seaming tape needed)
- Eliminates minor subfloor imperfections
- Adds thermal value and suitable for use with radiant heat flooring
- GREENGUARD Gold Certification
GREENGUARD Gold Certification offers stricter certification criteria, considers safety factors to account for sensitive individuals (such as children and the elderly), and ensures that a product is acceptable for use in environments such as schools and healthcare facilities. It is referenced by both The Collaborative for High Performance Schools (CHPS) and the Leadership in Energy and Environmental Design (LEED) Building Rating System.
Silencer SR™ is suitable for all Floating laminates, engineered and hardwood flooring installations.
Offers the best support, moisture protection and sound absorption for your floors.
| |
| |
- Reduces floor noise by providing excellent sound absorption
- Provides cushioned comfort under laminate and floating wood floors
- The Silencer SR™has high density and compression resistance properties that enable your floor to perform to its fullest potential and last a lifetime
- The moisture barrier film and tape strip combine to lock out moisture and allow for quick and easy installation
- Eliminates minor subfloor imperfections
- The Silencer SR™ adds insulation value with an R-value of .205
- Suitable for use with radiant heat flooring systems
- 100% recyclable, environmentally friendly, non allergenic and odorless
|
FLOOR PREPARATION
INSTALLATION
Quick and easy installation* – requires no additional seaming tape, cuts with a knife
- Subfloor should be clean and dry
- In geographic areas where concrete subfloors are subject to excessive moisture, a calcium chloride moisture test is required. Vapor emission readings in excess of 4 lbs. per 1,000 square feet in 24 hrs will require additional protection such as concrete sealant or polyethylene sheeting.
INSTALLATION
Quick and easy installation* – requires no additional seaming tape, cuts with a knife
- Install The Silencer SR™ with film DOWN on subfloor
- Roll out underlayment with tape strip next to wall. Roll out next row in same manner butting underlayment close to first row ( do not overlap ) and covering the moisture barrier film. Remove the tape strip and secure the overlapping moisture barrier film.
- Install flooring according to the manufacturer's installation instructions
*NOT for glue down installations
00% Synthetic SBR Rubber foam underlayment with attached polypropylene film
Thickness — .075"
Density — 14 LBS
Weight — 2.0 oz/sq.ft.
Moisture Barrier — with lip and tape sealing system
Thermal Resistance — R-Value .205
Compression Resistance @ 25% — 10.6 psi
Compression Set @ 25% — 20%
Flammability Rating — Passes Federal — Flammability Standards DOC-FF-1-70
Smoke Density — Passes, 85 max
Product Emissions — Exceeds VOC emissions requirements, environmentally friendlySOUND ABSORPTION PROPERTIES
Impact Insulation Class (IIC)
This method is to measure the impact sound transmission performance of a floor-ceiling assembly (sound transmission through the floor)
IIC – Flooring – Sub-Floor
70 – Laminate/Engineered – 6" concrete with ceiling assembly
59 – Hardwood – 6" concrete with ceiling assemblySound Transmission Class (STC) This method is to measure the air-borne sound insolating property of a partition element for effectiveness in blocking sound
STC – Flooring – Sub-Floor
71 – Laminate/Engineered – 6" concrete with ceiling assembly
53 – Hardwood – 6" concrete with ceiling assemblyDelta IIC The db rating difference between a floor measured with an underlayment and with no underlayment
Δ IIC 22
Thickness — .075"
Density — 14 LBS
Weight — 2.0 oz/sq.ft.
Moisture Barrier — with lip and tape sealing system
Thermal Resistance — R-Value .205
Compression Resistance @ 25% — 10.6 psi
Compression Set @ 25% — 20%
Flammability Rating — Passes Federal — Flammability Standards DOC-FF-1-70
Smoke Density — Passes, 85 max
Product Emissions — Exceeds VOC emissions requirements, environmentally friendly
SOUND ABSORPTION PROPERTIES Impact Insulation Class (IIC)
This method is to measure the impact sound transmission performance of a floor-ceiling assembly (sound transmission through the floor)
IIC – Flooring – Sub-Floor
70 – Laminate/Engineered – 6" concrete with ceiling assembly
59 – Hardwood – 6" concrete with ceiling assembly
Sound Transmission Class (STC) This method is to measure the air-borne sound insolating property of a partition element for effectiveness in blocking sound STC – Flooring – Sub-Floor
71 – Laminate/Engineered – 6" concrete with ceiling assembly
53 – Hardwood – 6" concrete with ceiling assembly
Delta IIC The db rating difference between a floor measured with an underlayment and with no underlayment Δ IIC 22
Available in 3' x 33.34' (100 sq. ft.) rolls and 6' x 75' (450 sq. ft.) contractor size rolls
| |
